Exposure EX4 OEM Conversion Kit for BMW R1300GS Adventure

More light. Not more lights.

Transform BMW's flagship adventure bike without adding extra light pods or creating a "Christmas tree" effect. Keep the clean OEM look while unlocking far more capable lighting in the original factory position.

Full ezCAN control with independently TÜV-tested, UN ECE R149-approved Exposure EX4s: independent day and night intensities for low/high beam, ultra-low 3% dimming, flash-to-pass and Dynamic Corner Blending.

A direct upgrade of the BMW OEM lighting

These are not extra lights bolted onto your R1300GS Adventure. The Exposure EX4 OEM Conversion Kit fully replaces the original BMW fog lights: the factory lights and air intakes are replaced by completely redesigned left and right air intake housings, each with an integrated Exposure EX4 in the original BMW light position.

You keep the clean, premium look of the R1300GSA, while the capability and control of the auxiliary lighting are completely transformed.

Full HEX ezCAN control

By controlling the EX4s through the HEX ezCAN, you get access to intelligent lighting functions, integrated with the controls and CAN-bus data the BMW already provides:

• Day intensity low beam
• Day intensity high beam
• Night intensity low beam
• Night intensity high beam
• Ultra-low dimming down to 3%
• Flash-to-pass strobing
• Dynamic Corner Blending

✓ TÜV-tested & UN ECE R149-approved

The Exposure EX4 has been independently tested by TÜV Rheinland Kraftfahrt GmbH in Germany and officially approved under UN ECE Regulation No. 149. Every EX4 carries the E11 approval mark.

Approval: UN ECE R149
Approval number: E11*149R01/06*1075*00
Classification: R-BS PL Driving Beam

Dynamic Corner Blending

Using the lean-angle data the bike already provides, Dynamic Corner Blending progressively adjusts the light output as the bike leans into a corner — intelligent lighting control normally only found in advanced factory systems.

Building the kit for your bike

The conversion is supplied as a configurable kit, so existing ezCAN owners only buy the parts they need.

The base conversion always includes:

• 2x Exposure EX4 lights
• Left replacement air intake/EX4 housing
• Right replacement air intake/EX4 housing

Removing the original BMW lights

The conversion can be fitted without cancellation dongles: the original BMW light units then stay electrically connected, are switched off via the bike's settings and stored safely inside the fairing.

Want to remove the factory lights completely? Then connect the optional OEM Fog Light Error Cancellation Dongles to the original BMW connectors, so the units can be removed without a dashboard error message.

Developed specifically for the R1300GS Adventure

The replacement left and right housings have been developed specifically around the R1300GS Adventure and the Exposure EX4. Made from ABS-GF glass-fibre-reinforced ABS, as 100% solid prints for strength and durability. The EX4 is integrated directly into the replacement housing, with the beam position adjusted during installation.

Key features

• Direct replacement of the BMW R1300GS Adventure OEM auxiliary lighting
• 2x Exposure EX4 lights
• Independently TÜV Rheinland-tested & UN ECE R149-approved (E11 mark)
• Purpose-developed left and right replacement air intake housings
• Clean OEM look, no extra external light pods
• Full HEX ezCAN integration
• Independent day and night light intensities
• Independent low/high beam settings
• EX4 dimming down to 3%
• Flash-to-pass strobing
• Dynamic Corner Blending
• Optional OEM fog light error cancellation dongles
• No modifications to the BMW factory wiring required

Small-batch production

This is a small-batch production run, so waiting times may increase — we actively monitor lead times and will keep you informed proactively.
